MOTECK CI73 - Interface Guide; 1. Overview

1. Overview
Setting switches
(Page 7~8)
Control terminal
(Page 5)
Power input
(Page 3)
Actuator power terminal
(Page 3~4)
Actuator signal terminal
(Page 3~4)
Synchronous communication ports
(Page 6)
Hand control socket
(Page 6)
LED indicator
Interface Guide
●
●
Pay attention to insulation protection during installation to avoid possible
risks and hazards for users to touch.
Please confirm the actuator specification before connecting, and fix the
actuator with appropriate mechanical installation.
