MOTECK CI73 - 5. Control Terminals

4. Control terminals
Port Definition Description
10
GND
G
11
Actuator retracts when switch on
RET
12
Actuator extends when switch on
EXT
14
Offline / Connection switching
Override
Remarks: For port ~ , the recommended cross-sectional area of each copper wire is 0.2mm
2
(24AWG).
10
14
The switches are prepared by customer
13
Triggered after switching on for > 2.0 seconds, the system will automatically
learn the stroke of the actuators
(see ‘Installation Steps / Operating Instructions’ step 6)
Learning
www.moteck.com
5
1213 1114 10
EXT
Learning
RET
Override
GND
