USER MANUAL 9
5. TECHNICAL SPECIFICATIONS
MECHANICAL FEATURES
ELECTRICAL FEATURES
MAIN FEATURES
Clear opening width, single leaf (mm): 750 - 1400
Clear opening width double leaf (mm): 1500 - 2800
Operator length, single leaf (mm): 1650 - 2850
Operator length double leaf (mm): 3100 - 5700
Opening speed: adjustable between 200 and 600 mm/s
Closing speed: 200 mm/s EN16005 “Low Energy”
Weight of the operator: 8-10 kg
OPERATOR DIMENSIONS (h x w)
60 x 70 mm
LEAF WEIGHT
Min. 5 kg - Max. 80 kg
OTHER DATA
Operating noise: < 50 dB
Use - continuous
Number of cycles: > 1.000.000
ADJUSTABLE PARAMETERS
Opening direction: right or left
Bistable Mode
“Low energy” or Normal mode
Opening speed
Hold open time
POWER SUPPLY
80-264 VAC/390 VDC & 47-63 Hz (Universal)
Maximum Power in Operation: 180 W
Fuse Protection: 2 A
Cable section: 3x1,5 mm
2
. Length 2 m
POWER CONSUMPTION
In motion: 80 W
Peaks (0,5 sec): 180 W
In stand-by < 4 W
MOTOR
Type: Linear LSMPM (Linear Synchronous Motor with
Permanent Magnets)
No. of poles: 4 Pitch pole: 50 mm No. of phases: 3
Voltage: 24 V DC
Permanent neodymium magnets
Force: < 100 N
CONTROL
Motion control by means of a driver with eld oriented
control (FOC)
Self-adjustment of clear opening
ACCESSORIES
Voltage: 24 V CC
Current: 1 A
OPERATING TEMPERATURE
Min: 5 ºC - Max: 40 ºC
