Memory Maps
1-31
1
$FFF58200 - $FFF5827F IP2 IP_c I/O D16 128B 7
$FFF58280 - $FFF582FF IP2 IP_c ID D16 128B 7
$FFF58300 - $FFF5837F IP2 IP_d I/O D16 128B 7
$FFF58380 - $FFF583FF IP2 IP_d ID Read D16 128B 7
$FFF58400 - $FFF584FF IP2 IP_ab I/O D32-D16 256B 1
$FFF58500 - $FFF585FF IP2 IP_cd I/O D32-D16 256B 7
$FFF58600 - $FFF586FF IP2 IP_ab I/O Repeated D32-D16 256B 1
$FFF58700 - $FFF587FF IP2 IP_cd I/O Repeated D32-D16 256B 7
$FFF58800 - $FFF5887F Reserved - - 128B 1
$FFF58880 - $FFF588FF Reserved - - 128B 1
$FFF58900 - $FFF5897F Reserved - - 128B 1
$FFF58980 - $FFF589FF Reserved - - 128B 1
$FFF58A00 - $FFF58A7F Reserved - - 128B 1
$FFF58A80 - $FFF58AFF Reserved - - 128B 1
$FFF58B00 - $FFF58B7F Reserved - - 128B 1
$FFF58B80 - $FFF58BFF Reserved - - 128B 1
$FFF58C00 - $FFF58CFF Reserved - - 256B 1
$FFF58D00 - $FFF58DFF Reserved - - 256B 1
$FFF58E00 - $FFF58EFF Reserved - - 256B 1
$FFF58F00 - $FFF58FFF Reserved - - 256B 1
$FFFBC000 - $FFFBC01F IP2 Registers D32-D8 2KB 1
$FFFBC800 - $FFFBC81F Reserved - - 2KB 1
Table 1-5. Local I/O Devices Memory Map (Continued)
Address Range Devices Accessed Port
Width
Size Notes
