1-8
Board Level Hardware Description
1
Specifications
Table 1-2 lists the specifications for a 700/800-series MVME162LX
without IPs.
Table 1-2. 700/800-Series MVME162LX: Specifications
Characteristics Specifications
Power requirements
(with EPROMs; without IPs)
+5Vdc ( 5%), 3.5 A typical, 4.5 A maximum
+12 Vdc ( 5%), 100 mA maximum
-12 Vdc ( 5%), 100 mA maximum
Operating temperature 0˚ to 70˚ C exit air with forced air cooling*
(see Note)
Storage temperature -40˚ to +85˚ C
Relative humidity 5% to 90% (noncondensing)
Physical dimensions
PC board with mezzanine
module only
Height
Depth
Thickness
PC board with connectors
and front panel
Height
Depth
Thickness
Double-high VMEboard
9.2 inches (233 mm)
6.3 inches (160 mm)
0.66 inch (17 mm)
10.3 inches (262 mm)
7.4 inches (188 mm)
0.80 inch (20 mm)
*Refer to Cooling Requirements on page 1-9 and Special Considerations for Elevated-
Temperature Operation on page 1-9.
