AP-621 Series Access Point Installation Guide
10
5. Attach the antennas to their correct connectors.
For information on available antennas, see “
Antenna Options” on page 5.
6. Place the large center opening of each of the mount slots over the screw heads.
7. Slide the access point down along the mounting surface to hang the mount slots on the
screw heads
8. Cable the access point using either the Power Injector or an approved line cord and power
supply.
For Motorola Power Injector installations:
a. Connect a RJ-45 CAT5e (or CAT6) Ethernet cable between the network data supply (host)
and the Power Injector Data In connector.
b. Connect a RJ-45 CAT5e (or CAT6) Ethernet cable between the Power Injector Data &
Power Out connector and the access point GE1/PoE port.
c. Ensure the cable length from the Ethernet source (host) to the Power Injector and
access point does not exceed 100 meters (333 ft). The Power Injector has no On/Off
power switch. The Power Injector receives power as soon as AC power is applied. For
more information on using the Power Injector, see “
LED Indicator” on page 15.
For power adapter (Part Number PWRS-147376-01R) and line cord installations:
a. Connect a RJ-45 CAT5e (or CAT6) Ethernet cable between the network data supply (host)
and the access point’s GE1/PoE.
b. Verify the power adapter is correctly rated according the country of operation.
c. Connect the power supply line cord to the power adapter.
d. Attach the power adapter cable to the DC-48V power connector on the access point.
e. Attach the power supply line cord to a power supply.
9. Verify the behavior of the LEDs. For more information, see “
LED Indicator” on page 15.
CAUTION Do not connect to the power source until the cabling of the access
point is complete. Ensure PoE is not connected to the access point’s
console connector or risk rendering the console connector
permanently inoperable.
!
