Hardware Installation
7
The 5 GHz antenna suite includes the following models:
For a more exhaustive overview of the antennas and associated components supported by the
Motorola Solutions access point family, refer to the Enterprise Wireless LAN Antenna Specification
Guide available at http://support.symbol.com/support/product/manuals.do
.
2.3.2 Power Injector System
The access point can receive power via an Ethernet cable connected to the GE1/PoE port.
When users purchase a WLAN solution, they often need to place access points in obscure locations.
In the past, a dedicated power source was required for each access point in addition to the Ethernet
infrastructure. This often required an electrical contractor to install power drops at each access point
location. The Power Injector merges power and Ethernet into one cable, reducing the burden of
installation and allowing optimal access point placement in respect to the intended coverage area.
The Power Injector (Part No. AP-PSBIAS-2P2-AFR) is an 802.3af PoE injector. The access point can
only use a Power Injector when connecting to the access point’s GE1/PoE port. The Power Injector is
separately ordered and not shipped with the access point. A separate Power Injector is required for
each access point comprising the network.
The Power Injector has no On/Off power switch. The Injector receives power and is ready for device
connection and operation as soon as AC power is applied. Refer to the guide shipped with the Power
Injector for a description of the device’s LEDs. The Power Injector can be installed free standing, on
an even horizontal surface or wall mounted using the Power Injector’s wall mounting key holes.
Part Number Antenna Type Approximate Gain (dBi)
ML-2452-APA2-01 Dipole 5
ML-2452-HPA5-036 Dipole 4.9
ML-5299-APA1-01R Dipole 2
ML-5299-HPA1-01R Dipole 5
ML-2452-APA2GA1-01 Dipole 1
ML-2452-PNA5-01R Panel 5
ML-2452-PTA3M3-36 Patch 3
ML-5299-PTA1-0R Patch 5
Internal Antenna PIFA 5.3
AP621 IG.book Page 7 Tuesday, September 20, 2011 3:18 PM
