AP-6511 Access Point Installation Guide
10
1. Remove the cover of the CAT5 wall plate.
2. Snap out keystone connectors from existing plate.
NOTE The example above assumes the Telco Box has a 1 RJ11 phonejack and
1 RJ-45 10/100 Ethernet connection.
