Hardware Installation
11
3. Gently pull some cable out of the wall so it can be used with the AP-6511 Access Point.
4. Attach the metal mounting plate (shipped with the AP-6511) to an existing standard Telco
in-wall box.
The screws used to mount the bracket to the Telco Box are customer provided. You can use
the same screws that are covered the existing wall plate if necessary.
Mount the AP-6511to the wall so the Telco Box is ready available behind the mounting plate.
