Defining a Basic AP-6511 Configuration
19
13. Make a Topology Selection based on your network’s configuration. The network topology
mode determines which options are available in the remainder of the Initial Setup Wizard.
• Router Mode - In Router Mode, the AP-6511 routes traffic between the local network
(LAN) and internet or external network (WAN).
• Bridge Mode - In Bridge Mode, the AP-6511 depends on an external router for routing
LAN and WAN traffic. Routing is generally used on one device, whereas bridging is
typically used for a larger density network.
For the purposes of this guide, Router Mode is selected, as Bridge Mode does not require
that all parameters be set.
14. Select Next to continue to the LAN Configuration screen.
