AP-7131 Series Access Point: Installation Guide
20
2.5.1 Three Radio AP-7131N LEDs
A three radio model AP-7131N has the following unique LED behavior:
LED 1 LED 2 (LAN) LED 3 (WAN) LED 4 - 5 GHz LED 5 - 2.4 GHz LED 6
Blinking Red
indicates
booting. Solid
Red defines the
diagnostic
mode.
White defines
normal
operation.
Green defines
normal GE1
operation.
Green defines
normal GE2
operation.
Blinking
Amber
indicates
802.11a activity.
A 5 second
Amber and
Yellow blink
rate defines
802.11an
activity.
A 2 second
Amber and
Yellow blink
rate defines
802.11an
(40 MHz)
activity.
When
functioning as a
sensor, LED
alternates
between
Amber and
Yellow.
The blink
interval is 0.5
seconds. It’s 1
second when no
Server is
connected.
Blinking
Emerald
indicates
802.11bg
activity.
A 5 second
Emerald and
Yellow blink
rate defines
802.11bgn
activity.
A 2 second
Emerald and
Yellow blink
rate defines
802.11bgn
(40 MHz)
activity.
When
functioning as a
sensor, LED
alternates
between
Emerald and
Yellow.
The blink
interval is 0.5
seconds. It’s 1
second when no
Server is
connected.
Blinking
Emerald
indicates the
radio is
defined as a
sensor, but is
disabled.
Alternates
between
Emerald and
Amber when
the radio is
defined as a
sensor with
no Server
connected.
The blink
interval is
1 second.
Alternates
between
Emerald and
Amber when
the radio is
defined as a
sensor and a
Server is
connected.
The blink
interval is
0.5 seconds
