2.5.2 Dual Radio (2.4/5 Ghz) LEDs
A dual radio (2.4/5 Ghz) model access point has the following unique LED behavior:
LED 1 LED 2 (LAN) LED 3 (WAN) LED 4 - 5 GHz LED 5 - 2.4 GHz LED 6
Blinking Red
indicates
booting.
Solid Red
defines the
diagnostic
mode.
White defines
normal
operation.
Green defines
normal GE1
operation.
Green defines
normal GE2
operation.
Blinking
Amber
indicates
802.11a activity.
A 5 second
Amber and
Yellow blink
rate defines
802.11an
activity.
A 2 second
Amber and
Yellow blink
rate defines
802.11an
(40 MHz)
activity.
When
functioning as a
sensor, LED
alternates
between
Amber and
Yellow.
The blink
interval is 0.5
seconds. It’s 1
second when no
Server is
connected.
Blinking
Emerald
indicates
802.11bg
activity.
A 5 second
Emerald and
Yellow blink
rate defines
802.11bgn
activity.
A 2 second
Emerald and
Yellow blink
rate defines
802.11bgn
(40 MHz)
activity.
When
functioning as a
sensor, LED
alternates
between
Emerald and
Yellow.
The blink
interval is 0.5
seconds. It’s 1
second when no
Server is
connected.
Not Used
