Installation Guide 39
To use the extension arm with the mounting hardware kit:
1. With the open slot connections facing down, attach the angle adjust bracket section at the desired
mounting location using four #10/32 lag bolts.
2. Complete the steps for assembling and positioning the angle adapter bracket and Access Point bracket
sections outlined above. See
Vertical Pole Mount on page 26.
