Motorola APX 2000 User Manual

•
or to TMS and press the Menu Select
button directly below TMS to access the TMS
feature screen.
2
or to Sent and press the Menu Select
button below Sel.
The display shows a list of aliases or IDs, with the
recipient of latest sent message on top.
3 or to the required aliases or ID and press
the Menu Select button below Sel to view the
message.
While on the view message screen, press the
Menu Select button directly below Optn, Del or
Back to access the option.
•
Select Optn to configure the message settings.
•
Select Del to delete the message.
•
Select Back to return to the previous screen.
Note: The icon at the top right corner of the
screen indicates the status of the message. See
Text Messaging Service (TMS) Indicators on page
50 for more information.
Sending a Sent Text Message
1
Press the Menu Select button directly below Optn
while viewing the message.
2
or to Send Message and press the Menu
Select button directly below Sel.
3 Perform one of the following actions:
• or to scroll through the address list and
highlight the required address.
•
or to [Other Recpnt] and press the
Menu Select button below Edit. When a
blinking cursor appears in the Enter Address
screen, use the keypad to type the address
entry.
4
Press the Menu Select button below Send or the
PTT button to send the message.
The display shows the Send Message screen and
Sending msg.
Note: Press the Menu Select button directly
below Back at any time to return to the previous
screen.
Advanced Features
114
English

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
