Motorola APX 2000 User Manual

See the following picture for two knobs
radio.
2
To remove the battery, lift up the latch ( ) which is
at the bottom of the radio, then slide the battery
out from the radio.
Note: When removing the battery, ensure that the
radio is turned off.
See the following picture for MFK radio.
Preparing Your Radio for Use
21
English

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
