Motorola APX 3000

Identifying Radio Controls
English
17
Radio Parts and Controls
Transmit/
Receive LED
12
Top Button*
1
On/Off Switch
2
Middle Side
Button*
4
Battery
13
Battery
Connector
* These radio controls/buttons are programmable.
Top Side
Button*
3
14
Bluetooth
Pairing
Spot
Antenna
8
Up Arrow
Button*
5
Down Arrow
Button*
6
Connector
Cover
9
Bluetooth
LED
10
11
Battery Latch
7
