Identifying Status Indicators
Your radio indicates its operational status through the following:
Status Icons‡. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
LED Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 23
LED Indicators in Surveillance Mode† . . . . . . . . . . . page 24
Intelligent Lighting Indicators‡. . . . . . . . . . . . . . . . . . . page 25
Alert Tones† . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 26
Status Icons‡
The 112 x 32 pixel monochrome display screen of your DRSM
shows your radio status and operating conditions.
Battery
For IMPRES™ battery operation only – the icon
shown indicates the charge remaining in the
battery.
For all battery operation – the icon blinks when
the battery is low.
Received Signal Strength Indicator (RSSI)
The number of bars displayed represents the
received signal strength for the current site, for
trunking only. The more stripes in the icon, the
stronger the signal.
U
V
Roaming
The radio has roamed to and is currently
registered to a foreign system.
Direct
• On = Radio is currently configured for direct
radio to radio communication (during
conventional operation only).
• Off = Radio is connected with other radios
through a repeater.
Monitor (Carrier Squelch)
Selected channel is being monitored (during
conventional operation only).
Power Level
• L = Radio is set at Low power.
• H = Radio is set at High power.
Scan
Radio is scanning.
N
M
H or L
J
