48 Specifications
8.1.7 General
8.1.8 Others
Limited Front Panel Configuration
( Dimension W x D X H)
16” x 18.1” x 4.2” (406 x 457 x 107mm)
Full Feature Front Panel
Configuration
(Dimension W x D x H)
16" x 18.75" x 4.2" (406 x 476 x 107mm)
Limited Front Panel Configuration
(Weight)
18.5 lbs (8.4 kg)
Full Feature Front Panel
Configuration (Weight)
19.5 lbs (8.9 kg)
Wireline Specification
Wireline Configuration 2-wire or 4-wire capable; 600ohm or bridging impedances.
Guard Tones 2175Hz(Default), 2100Hz, 2300Hz and 2325Hz.
Function Tones 450Hz - 2050Hz in 100Hz increments.
Tone Tolerance ±10Hz
Range of detection -30dBm to +13dBm
Wireline Connector RJ45
Wireline Surge TIA-968-A, Section 4.2.2
Type A Surge Metallic: A peak voltage of at least 800V and a peak
short circuit current of at least 100A.
Type A Surge Longitudinal: A peak voltage of at least 1500V and a
peak short circuit current of at least 200A.
ACIM Specification
ACIM Signal Levels RS232; 2-wire operation only
ACIM Connector Type RJ45
USB Specifications
USB Connector Type Type A (Host), Type B (Device)
Data Rate USB 1.1 Full Speed Compliant
Allowable Accessories See Target Peripheral List
E&M Specifications
Input Qty 1, for PTT, active LOW
Input Rating 5.5V, 12mA MAX
Relay Output Qty 1, follows channel activity.
Relay Output Type Form A, SPST, normally open solid state relay, 350V, 120 mA MAX.
