Exploded Views and Parts Lists: W4 Rotary Control Head Exploded View 7-3
6881096C77-O September 26, 2003
7.2 W4 Rotary Control Head Exploded View
Figure 7-2. W4 Rotary Control Head Exploded View
Table 7-3. Model W4 Rotary Control Head Parts List
Item No. Motorola Part No. Description
1 0380077M01 SCREW, Control Head Mounting (Qty 2)
2 3602113Z05 KNOB, Volume Control
3 3205805V01 GASKET, W4 Shaft (Qty 2)
4 0284218M01 NUT, Volume Switch
5 0484219M01 LOCKWASHER, Volume Switch
6 1502117Z07 or
1502117Z08
HOUSING, Front Cover (Mobile)
HOUSING, Front Cover (Motorcycle)
7 0102709J83 ASSEMBLY, Volume and Rotary Switch
8 3602113Z03 KNOB, Mode Control
9 3205805V01 GASKET, W4 Shaft (Qty 2)
10 0284218M02 NUT, Mode Switch
11 0484219M02 LOCKWASHER, Mode Switch
12 6105129X01 LIGHTPIPE
13 7505128X01 KEYPAD
14 AAHN4045_ or
PMLN4019_
ASSEMBLY, Circuit Board (Mobile)
ASSEMBLY, Circuit Board (Motorcycle)
15 4302112Z02 SPACER, Internal
16 0310945A14 SCREW, Machine (Qty 4)
17 3280289L02 GASKET, Housing
18 HLN6401_ ASSEMBLY, Circuit Board Interconnect
Notes: _ = The latest version kit. When ordering, refer to your specific kit
for this suffix letter.
The HKN4356_ Radio Cable is used to remote mount the W4
Control Head.
