Motorola CP150 Basic Service Manual

UHF 438-470 MHz 7-5
7.5 UHF 438-470 MHz
CP150/CP200, UHF, 438-470 MHz
Model Description
AAH50RCC9AA1AN CP150, 438-470 MHz, 2W, 4 Ch.
AAH50RCC9AA2AN CP150, 438-470 MHz, 2W, 16 Ch.
AAH50RDC9AA1AN CP200, 438-470 MHz, 4W, 4 Ch.
AA50RDC9AA2AN CP200, 438-470 MHz, 4W, 16 Ch.
Item Description
X PMUE1953_A CP150, 438-470 MHz, 2W, 4 Ch.
X PMUE1955_A CP150, 438-470 MHz, 2W, 16 Ch.
X PMUE1949_A CP200, 438-470 MHz, 4W, 4 Ch.
X PMUE1951_A CP200, 438-470 MHz, 4W, 16 Ch.
X PMLE4255_ CP200, Back Cover Kit,. 438-470, 4 Ch.
X PMLE4254_ CP200, Back Cover Kit, 438-470 MHz, 16 Ch.
X PMLE4256_ CP150, Back Cover Kit, 438-470 MHz, 4 Ch.
X PMLE4257_ CP150, Back Cover Kit, 438-470 MHz, 4 Ch.
X X PMLN4552_ Plain, Front Housing Kit, 4 Ch.
X X PMLN4553_ Plain, Front Housing Kit, 16 Ch.
X X X X NNTN4496_R NiCd Battery, 1100 mAH
X X X X NNTN4497_R Li-Ion Battery, 1800 mAH
X X X X NNTN4851_R NiMH Battery, 1400 mAH
XXXXNNTN4970_R Slim Li-Ion Battery, 1600 mAH
X X X X WPLN4138_R Rapid 90-Min. Desktop Charger w/US Plug
XXXXHLN8255 3” Belt Clip
X X X X NAE6483_R Antenna, Flexible Whip, 403-520 MHz
XXXX6880309N60 CP150/CP200 User Guide, English/French
X X X X HKLN4220 CP150/CP200 User Guide CDROM, English/French
X = Indicates compatibility with model(s)

Motorola CP150 Specifications

General

Channels	16
Audio Output	500 mW
Channel Spacing	12.5/25 kHz
Operating Temperature	-30°C to +60°C
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Power Supply	Rechargeable battery pack
