13-17 Circuit Board/Schematic Diagram and Parts List (UHF1: 403–447 MHz)
F-
CABLE1
BGTech 8560228005000 SNAGGWA, BEACON FLAT
CABLE, FF12-22N080XXA
F-
CABLE2
BGTech 8560124005001 SNAGGWA, BEACON FLAT
CABLE, FF12-12N040XXA
FL101 BGTech 82827R3728M00 SHINSUNG, Crystal,
7.3728MHz (H: 2.8mm)
FL102 BGTech 82827R5795M00 SHINSUNG, Crystal,
3.5795MHz (H: 2.8mm)
FL201 BGTech 828244R645M00 SHINSUNG, Crystal,
44.645MHz (SMD)
FL301 BGTech 828645R100220 SHINSUNG, Crystal, MCF
45.15S12.B (8.5KHz)
FL701 BGTech 8289012R80010 SHINSUNG, VCTCXO, 12.8
MHZ
J101 BGTech 851607C01S110 YUNHO, FPC CONNECTOR,
05004HR-07C01S(G)
J102 BGTech 851622A01S110 YUNHO, FPC CONNECTOR,
05004HR-22A01S
J103 BGTech 8516220005020 KYOCERA, FPC CONNEC-
TOR, 04-6292-022-000-800+
J104 BGTech 851612151A110 OMIRON, FPC CONNEC-
TOR, XF2M-1215-1A
J105 BGTech 8516220R50100 MOLEX, FPC CONNEC-
TOR, 52745-1297
J601 BGTech 8500031009800 CHI CHENG, SPK MIC
JACK, 0980683Z01-D
J602 BGTech 85100G500PL00 SUYIN, BATTERY CONNEC-
TOR, 060031MA005G500PL
J603 BGTech 8510530470210 MOLEX, CONNECTOR,
53047-0210
L 3 0 1 DAERIM N/A COIL AIR, 0.45-1.4-
5TL(SMD)
L304 TAIYOYUDEN N/A Chip Ind, 1005 J 39N
L306 TAIYOYUDEN N/A Chip Ind, 1005 J 33N
L310 TAIYOYUDEN N/A Chip Ind, 1005 J 22N
L320 DELTA N/A Chip Ind, 2012 27nH
L323 DELTA N/A Chip Ind, 2012 27nH
L324 DELTA N/A Chip Ind, 2012 27nH
L325 DELTA N/A Chip Ind, 2012 220nH
Circuit
Ref.
Supplier Supplier Part No. Description
L327 TAIYOYUDEN N/A Chip Ind,1608 K 820NH
L328 DELTA N/A Chip Ind, 2012 27nH
L329 BGTech 8920PT1667020 TOKO, #617PT-1667
L331 TAIYOYUDEN N/A Chip Ind, 1005 J 22N
L332 TAIYOYUDEN N/A Chip Ind,1608 K 220NH
L333 BGTech 8920PT1667020 TOKO, #617PT-1667
L334 KAMAYA N/A Chip Res, 1005 J 0?
L340 DELTA N/A Chip Ind, 2012 820nH
L401 TAIYOYUDEN N/A Chip Ind, 1608 27nH J
L402 TAIYOYUDEN N/A Chip Ind, 1608 22nH J
L403 TAIYOYUDEN N/A Chip Ind, 1608 33nH J
L405 TAIYOYUDEN N/A Chip Ind, 1608 6.8nH J
L406 TAIYOYUDEN N/A C h i p I n d , 1 6 0 8 2 2 0 n H J
L407 TAIYOYUDEN N/A Chip Ind, 1005 J 33nH
L409 DAERIM N/A COIL AIR, 0.45-1.4-
3TL(SMD)
L 4 1 0 D A E R I M N / A C O I L A I R , 0 . 4 5 - 1 . 4 -
3TL(SMD)
L411 DAERIM N/A COIL AIR, 0.45-1.4-
3TL(SMD)
L412 TAIYOYUDEN N/A Chip Ind, 1608 220nH J
L 4 1 3 DAERIM N/A COIL AIR, 0.35-1.6-
7TL(SMD)
L601 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L602 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L603 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L604 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L605 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L701 TAIYOYUDEN N/A C h i p I n d , 1 0 0 5 J 2 7 n H
L702 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
L703 DAERIM N/A COIL AIR, 0.30-1.1-
3TL(SMD)
L704 TAIYOYUDEN N/A Chip Ind, 1608 220nH J
L705 TAIYOYUDEN N/A Chip Ind, 1608 K 2.2uH
Circuit
Ref.
Supplier Supplier Part No. Description
L 7 0 6 D A E R I M N / A C O I L A I R , 0 . 3 0 - 1 . 1 -
3TL(SMD)
L707 TAIYOYUDEN N/A C h i p I n d , 1 6 0 8 2 2 0 n H J
L708 TAIYOYUDEN N/A Chip Ind, 1005 J 27nH
L709 TAIYOYUDEN N/A Chip Ind, 1005 J 22nH
LCD1 BGTech 86343208A2020 EVERRVIEW,VBS3208A2-
7FWLYA,REV4.0
MIC1 BGTech 8420063215000 BSE, C-MIC, 6.0*2.7/2.2KW
,2V,-44±3dB, Pin type
PB501 BGTech 8466PUD02K020 PANASONIC, Tack Switch,
EVQPUD02K
PB502 BGTech 8466PUD02K020 PANASONIC, Tack Switch,
EVQPUD02K
PB503 BGTech 8466PUD02K020 PANASONIC, Tack Switch,
EVQPUD02K
Q101 KEC N/A KRC 413 BJT NPN Transistor
Q102 KEC N/A KRC 413 BJT NPN Transistor
Q103 KEC N/A KRC 413 BJT NPN Transistor
Q104 KEC N/A KRC 413 BJT NPN Transistor
Q110 KEC N/A KRC 101 BJT NPN Transistor
Q111 KEC N/A KTA 2014 BJT PNP
Transistor
Q112 KEC N/A KTA 2014 BJT PNP
Transistor
Q113 KEC N/A KRC 404 BJT NPN Transistor
Q114 KEC N/A KRC 404 BJT NPN Transistor
Q120 KEC N/A KRC 404 BJT NPN Transistor
Q121 KEC N/A KRC 404 BJT NPN Transistor
Q122 KEC N/A KRC 404 BJT NPN Transistor
Q201 KEC N/A KRC 404 BJT NPN Transistor
Q202 KEC N/A KRC 404 BJT NPN Transistor
Q206 KEC N/A KRC 404 BJT NPN Transistor
Q207 KEC N/A KRC 404 BJT NPN Transistor
Q301 HITACH N/A 2SC4901 BJT NPN Transis-
tor
Circuit
Ref.
Supplier Supplier Part No. Description
