Circuit Board/Schematic Diagram and Parts List (UHF1: 403–447 MHz) 13-18
Q303 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q304 KEC N/A KRA 305 BJT PNP Transistor
Q305 KEC N/A KRC 404 BJT NPN Transistor
Q308 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q401 BGTech 8142000951120 PBR 951LT1 PHILIPS BJT
NPN Transistor
Q402 BGTech 8149003078021 2SK3078A TOSHIBA FET N-
channel Transistor
Q403 BGTech 8149003476021 2SK3476 TOSHIBA FET N-
channel Transistor
Q404 BGTech 8145001188021 STB 1188 AUK BJT NPN
Transistor
Q405 KEC N/A KTC 4075 BJT NPN Transis-
tor
Q406 KEC N/A KRC 404 BJT NPN Transistor
Q407 KEC N/A KRA 305 BJT PNP Transistor
Q408 KEC N/A KRC 404 BJT NPN Transistor
Q409 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q501 KEC N/A KRC 404 BJT NPN Transistor
Q502 KEC N/A KRC 404 BJT NPN Transistor
Q503 KEC N/A KRC 404 BJT NPN Transistor
Q504 KEC N/A KRC 404 BJT NPN Transistor
Q505 KEC N/A KRA 305 BJT PNP Transistor
Q601 KEC N/A KRC 404 BJT NPN Transistor
Q602 KEC N/A KRC 404 BJT NPN Transistor
Q701 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q702 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q703 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q704 NEC N/A 2SC4226 BJT NPN Transis-
tor
Q705 KEC N/A KRA 305 BJT PNP Transistor
Circuit
Ref.
Supplier Supplier Part No. Description
Q706 KEC N/A KRA 305 BJT PNP Transistor
Q707 KEC N/A KTC 4075 BJT NPN Transis-
tor
Q708 KEC N/A KTA 2014 BJT PNP Transis-
tor
Q709 KEC N/A KTA 2014 BJT PNP Transis-
tor
Q710 KEC N/A KTC 4075 BJT NPN Transis-
tor
Q711 KEC N/A KRA304 BJT PNP Transistor
R101 KAMAYA N/A Chip Res, 1005 J 10KW
R102 KAMAYA N/A Chip Res, 1005 J 47KW
R103 KAMAYA N/A Chip Res, 1005 J 150KW
R104 KAMAYA N/A Chip Res, 1005 J 47KW
R105 KAMAYA N/A Chip Res, 1005 J 47KW
R106 KAMAYA N/A Chip Res, 1005 J 47KW
R107 KAMAYA N/A Chip Res, 1005 J 3.9KW
R108
1
KAMAYA N/A Chip Res, 1005 J 4.7KW
R109
1
KAMAYA N/A Chip Res, 1005 J 4.7KW
R110 KAMAYA N/A Chip Res, 1005 J 270KW
R112
1
KAMAYA N/A Chip Res, 1005 J 4.7KW
R113 KAMAYA N/A Chip Res, 1005 J 47KW
R114 KAMAYA N/A Chip Res, 1005 J 10KW
R115 KAMAYA N/A Chip Res, 1005 J 10KW
R116 KAMAYA N/A Chip Res, 1005 J 1.2KW
R117 KAMAYA N/A Chip Res, 1005 J 8.2KW
R118 KAMAYA N/A Chip Res, 1005 J 47KW
R119
1
KAMAYA N/A Chip Res, 1005 J 4.7KW
R120 KAMAYA N/A Chip Res, 1005 J 47KW
R121 KAMAYA N/A Chip Res, 1005 J 330KW
R122 KAMAYA N/A Chip Res, 1005 J 330KW
R126 KAMAYA N/A Chip Res, 1005 J 15KW
R127 KAMAYA N/A Chip Res, 1005 J 33KW
Circuit
Ref.
Supplier Supplier Part No. Description
R128 KAMAYA N/A Chip Res, 1005 J 3.9KW
R129 KAMAYA N/A Chip Res, 1005 J 150KW
R131 KAMAYA N/A Chip Res, 1005 J 10W
R132 KAMAYA N/A Chip Res, 1005 J 1KW
R132 KAMAYA N/A Chip Res, 1005 J 220KW
R133 KAMAYA N/A Chip Res, 1005 J 680KW
R134 KAMAYA N/A Chip Res, 1005 J 3.9MW
R135 TDK N/A Chip Cap,1005 K 0.1μF
R136 KAMAYA N/A Chip Res, 1005 J 100KW
R137 KAMAYA N/A Chip Res, 1005 J 4.7MW
R138 KAMAYA N/A Chip Res, 1005 J 220KW
R139 KAMAYA N/A Chip Res, 1005 J 10KW
R140 KAMAYA N/A Chip Res, 1005 J 68KW
R141 KAMAYA N/A Chip Res, 1005 J 100KW
R142 KAMAYA N/A Chip Res, 1005 J 330KW
R143 KAMAYA N/A Chip Res, 1005 J 100KW
R144 KAMAYA N/A Chip Res, 1005 J 100KW
R145 KAMAYA N/A Chip Res, 1005 J 1MW
R146 KAMAYA N/A Chip Res, 1005 J 0W
R147 KAMAYA N/A Chip Res, 1005 J 47KW
R148 KAMAYA N/A Chip Res, 1005 J 1MW
R149 KAMAYA N/A Chip Res, 1005 J 470KW
R150 KAMAYA N/A Chip Res, 1005 F 10KW
R151 KAMAYA N/A Chip Res, 1005 F 12KW
R152 KAMAYA N/A Chip Res, 1005 J 680W
R153 KAMAYA N/A Chip Res, 1005 F 68KW
R154 KAMAYA N/A Chip Res, 1005 F 47KW
R155 KAMAYA N/A Chip Res, 1005 J 470W
R156 KAMAYA N/A Chip Res, 1005 J 1KW
R157
1
KAMAYA N/A Chip Res, 1005 J 1KW
R158
1
KAMAYA N/A Chip Res, 1005 J 1KW
R159 KAMAYA N/A Chip Res, 1005 J 47KW
Circuit
Ref.
Supplier Supplier Part No. Description
