Motorola EP350 - Page 69

Circuit Board/Schematic Diagram and Parts List (UHF2: 435–480 MHz) 7-23
R190 KAMAYA – Chip Res, 1005 J 15KΩ
R193 KAMAYA – Chip Res, 1005 J 10KΩ
R194 KAMAYA – Chip Res, 1005 J 10KΩ
R195 KAMAYA – Chip Res, 1005 J 100Ω
R196 KAMAYA – Chip Res, 1005 J 47KΩ
R197 KAMAYA – Chip Res, 1005 J 47KΩ
R198 KAMAYA – Chip Res, 1005 J 47KΩ
R199 KAMAYA – Chip Res, 1005 J 47KΩ
R203 KAMAYA – Chip Res, 1005 J 22KΩ
R204 KAMAYA – Chip Res, 1005 J 22KΩ
R206 KAMAYA – Chip Res, 1005 J 10KΩ
R207 KAMAYA – Chip Res, 1005 J 22KΩ
R208 KAMAYA – Chip Res, 1005 J 12KΩ
R210 KAMAYA – Chip Res, 1005 J 120KΩ
R211 KAMAYA – Chip Res, 1005 J 15KΩ
R212 KAMAYA – Chip Res, 1005 J 33KΩ
R213 KAMAYA – Chip Res, 1005 J 3.3KΩ
R216 KAMAYA – Chip Res, 1005 J 10KΩ
R217 KAMAYA – Chip Res, 1005 J 10KΩ
R220 KAMAYA – Chip Res, 1005 J 5.6KΩ
R250 KAMAYA – Chip Res, 1005 J 10KΩ
R258 KAMAYA – Chip Res, 1005 J 1.5KΩ
R302 KAMAYA – Chip Res, 1005 J 56KΩ
R309 KAMAYA – Chip Res, 1005 J 100Ω
R310 KAMAYA – Chip Res, 1005 J 4.7KΩ
R311 KAMAYA – Chip Res, 1005 J 330Ω
R312 KAMAYA – Chip Res, 1005 J 150KΩ
R314 KAMAYA – Chip Res, 1005 J 100Ω
R315 KAMAYA – Chip Res, 1005 J 100Ω
R316 KAMAYA – Chip Res, 1005 J 100KΩ
Circuit
Ref.
Supplier Supplier Part No. Description
R317 KAMAYA – Chip Res, 1005 J 180KΩ
R318 KAMAYA – Chip Res, 1005 J 3.3KΩ
R319 KAMAYA – Chip Res, 1005 J 3.3KΩ
R320 KAMAYA – Chip Res, 1005 J 100Ω
R323 KAMAYA – Chip Res, 1005 J 100KΩ
R330 KAMAYA – Chip Res, 1005 J 100KΩ
R332 KAMAYA – Chip Res, 1005 J 100KΩ
R333 KAMAYA – Chip Res, 1005 J 100KΩ
R334 KAMAYA – Chip Res, 1005 J 100KΩ
R335 KAMAYA – Chip Res, 1005 J 2.2KΩ
R336 KAMAYA – Chip Res, 1005 J 1KΩ
R337 KAMAYA – Chip Res, 1005 J 100Ω
R338 KAMAYA – Chip Res, 1005 J 100Ω
R401 KAMAYA – Chip Res, 1005 J 180Ω
R402 KAMAYA – Chip Res, 1005 J 39Ω
R403 KAMAYA – Chip Res, 1005 J 180Ω
R404 KAMAYA – Chip Res, 1005 J 8.2KΩ
R405 KAMAYA – Chip Res, 1005 J 1.5KΩ
R406 KAMAYA – Chip Res, 1005 J 22Ω
R407 KAMAYA – Chip Res, 1005 J 4.7KΩ
R408 KAMAYA – Chip Res, 1005 J 2.2KΩ
R409 KAMAYA – Chip Res, 1005 J 10Ω
R410 KAMAYA – Chip Res, 1005 J 10Ω
R411 KAMAYA – Chip Res, 1005 J 560Ω
R412 KAMAYA – Chip Res, 1005 J 1KΩ
R413 KAMAYA – Chip Res, 1005 J 8.2KΩ
R414 KAMAYA – Chip Res, 1005 J 1KΩ
R415 KAMAYA – Chip Res, 2012 J 220Ω
R416 KAMAYA – Chip Res, 1608 J 47KΩ
R417 ROHM – Chip Res, 1W J 2512 0.1Ω
Circuit
Ref.
Supplier Supplier Part No. Description
R418 KAMAYA – Chip Res, 1608 D 220KΩ
R419 KAMAYA – Chip Res, 1608 D 220KΩ
R420 KAMAYA – Chip Res, 1005 J 4.7MΩ
R421 KAMAYA – Chip Res, 1608 D 68KΩ
R422 KAMAYA – Chip Res, 1608 D 68KΩ
R423 KAMAYA – Chip Res, 1005 J 3.9MΩ
R424 KAMAYA – Chip Res, 1005 J 12KΩ
R425 KAMAYA – Chip Res, 1005 J 3.9KΩ
R426 KAMAYA – Chip Res, 1005 J 4.7KΩ
R427 KAMAYA – Chip Res, 1005 J 220KΩ
R428 KAMAYA – Chip Res, 1005 J 100Ω
R429 KAMAYA – Chip Res, 1005 J 3.6KΩ
R430 KAMAYA – Chip Res, 1005 J 100Ω
R431 KAMAYA – Chip Res, 1005 J 10KΩ
R432 KAMAYA – Chip Res, 1005 J 27KΩ
R433 KAMAYA – Chip Res, 1005 J 0Ω
R434 KAMAYA – Chip Res, 1005 J 33KΩ
R435 KAMAYA – Chip Res, 1005 J 150Ω
R436 KAMAYA – Chip Res, 1005 J 100Ω
R440 KAMAYA – Chip Res, 1005 J 15KΩ
R441 KAMAYA – Chip Res, 1005 J 0Ω
R501 KAMAYA – Chip Res, 1005 J 220Ω
R502 KAMAYA – Chip Res, 1005 J 220Ω
R503 KAMAYA – Chip Res, 1005 J 56KΩ
R504 NOBLE – Chip Semi V.R, 3PIE 47
KΩ
R505 KAMAYA – Chip Res, 1005 J 12KΩ
R506 KAMAYA – Chip Res, 1005 J 10KΩ
R507 KAMAYA – Chip Res, 1005 J 10KΩ
R508 KAMAYA – Chip Res, 1005 J 3.6KΩ
R509 KAMAYA – Chip Res, 1005 J 2.2KΩ
Circuit
Ref.
Supplier Supplier Part No. Description
