7-24 Circuit Board/Schematic Diagram and Parts List (UHF2: 435–480 MHz)
R510 KAMAYA – Chip Res, 1005 J 15KΩ
R511 KAMAYA – Chip Res, 1005 J 8.2KΩ
R512 KAMAYA – Chip Res, 1005 J 20KΩ
R513 KAMAYA – Chip Res, 1005 J 10KΩ
R514 KAMAYA – Chip Res, 1005 J 15KΩ
R515 KAMAYA – Chip Res, 1005 J 20KΩ
R516 KAMAYA – Chip Res, 1005 J 2.2KΩ
R517 KAMAYA – Chip Res, 1005 J 15KΩ
R518 KAMAYA – Chip Res, 1005 J 4.7KΩ
R519 KAMAYA – Chip Res, 1005 J 4.7MΩ
R520 KAMAYA – Chip Res, 1005 J 1MΩ
R521 KAMAYA – Chip Res, 1005 J 330KΩ
R523 KAMAYA – Chip Res, 1005 F 30KΩ
R524 KAMAYA – Chip Res, 1005 F 47KΩ
R526 NOBLE – Chip Semi V.R, 2PIE 47
KΩ
R527 KAMAYA – Chip Res, 1005 J 82KΩ
R528 KAMAYA – Chip Res, 1005 J 82KΩ
R529 KAMAYA – Chip Res, 1005 J 47KΩ
R530 KAMAYA – Chip Res, 1005 J 47KΩ
R531 KAMAYA – Chip Res, 1005 J 47KΩ
R532 KAMAYA – Chip Res, 1005 J 10KΩ
R533 KAMAYA – Chip Res, 1005 J 10KΩ
R534 KAMAYA – Chip Res, 1005 J 10KΩ
R535 KAMAYA – Chip Res, 1005 J 10KΩ
R536 KAMAYA – Chip Res, 1005 J 330KΩ
R537 KAMAYA – Chip Res, 1005 J 1KΩ
R538 KAMAYA – Chip Res, 1005 J 10KΩ
R539 KAMAYA – Chip Res, 1005 J 330KΩ
R540 KAMAYA – Chip Res, 1005 J 47KΩ
R541 KAMAYA – Chip Res, 1005 J 330KΩ
Circuit
Ref.
Supplier Supplier Part No. Description
R609 KAMAYA – Chip Res, 1005 J 1KΩ
R610 KAMAYA – Chip Res, 1005 J 2.2Ω
R613 KAMAYA – Chip Res, 1005 J 15KΩ
R614 KAMAYA – Chip Res, 1005 J 390KΩ
R615 KAMAYA – Chip Res, 1005 J 2.2Ω
R616 KAMAYA – Chip Res, 1005 J 0Ω
R619 KAMAYA – Chip Res, 1005 J 10KΩ
R620 KAMAYA – Chip Res, 1005 J 33KΩ
R621 KAMAYA – Chip Res, 1005 J 39KΩ
R622 KAMAYA – Chip Res, 1005 J 0Ω
R623 KAMAYA – Chip Res, 1005 J 560Ω
R701 KAMAYA – Chip Res, 1005 J 56Ω
R702 KAMAYA – Chip Res, 1005 J 1.5KΩ
R703 KAMAYA – Chip Res, 1005 F 4.7KΩ
R704 KAMAYA – Chip Res, 1005 F 4.7KΩ
R705 KAMAYA – Chip Res, 1005 J 220Ω
R706 KAMAYA – Chip Res, 1005 J 100Ω
R707 KAMAYA – Chip Res, 1005 J 1.5KΩ
R708 KAMAYA – Chip Res, 1005 F 4.7KΩ
R709 KAMAYA – Chip Res, 1005 F 6.8KΩ
R710 KAMAYA – Chip Res, 1005 J 220Ω
R711 KAMAYA – Chip Res, 1005 J 100KΩ
R712 KAMAYA – Chip Res, 1005 J 100KΩ
R713 KAMAYA – Chip Res, 1005 J 30KΩ
R714 KAMAYA – Chip Res, 1005 J 56Ω
R715 KAMAYA – Chip Res, 1005 J 56Ω
R716 KAMAYA – Chip Res, 1005 J 300Ω
R717 KAMAYA – Chip Res, 1005 J 10Ω
R718 KAMAYA – Chip Res, 1005 J 7.5KΩ
R719 KAMAYA – Chip Res, 1005 J 1KΩ
Circuit
Ref.
Supplier Supplier Part No. Description
R720 KAMAYA – Chip Res, 1005 J 150Ω
R721 KAMAYA – Chip Res, 1005 J 150Ω
R722 KAMAYA – Chip Res, 1005 J 10KΩ
R723 KAMAYA – Chip Res, 1005 J 1KΩ
R724 KAMAYA – Chip Res, 1005 J 390Ω
R725 KAMAYA – Chip Res, 1005 J 100Ω
R726 KAMAYA – Chip Res, 1005 J 3KΩ
R727 KAMAYA – Chip Res, 1005 J 2.7KΩ
R728 KAMAYA – Chip Res, 1005 J 2.7KΩ
R729 KAMAYA – Chip Res, 1005 J 100KΩ
R730 KAMAYA – Chip Res, 1005 J 33KΩ
R731 KAMAYA – Chip Res, 1005 J 10Ω
R732 KAMAYA – Chip Res, 1005 J 10KΩ
R733 KAMAYA – Chip Res, 1005 J 0Ω
R734 KAMAYA – Chip Res, 1005 J 10Ω
R735 KAMAYA – Chip Res, 1005 J 1KΩ
R736 KAMAYA – Chip Res, 1005 J 1KΩ
R737 KAMAYA – Chip Res, 1005 J 1KΩ
R740 KAMAYA – Chip Res, 1005 J 1.5KΩ
R1001 KAMAYA – Chip Res, 1005 J 10KΩ
R1002 KAMAYA – Chip Res, 1005 J 9.1KΩ
R1003 KAMAYA – Chip Res, 1005 J 10KΩ
R1004 KAMAYA – Chip Res, 1005 J 10KΩ
R1005 TDK – Chip Cap, 1005 K 10nF
RT201 TAIYOYUDEN – Thermistor, 103K
RT501 TAIYOYUDEN – Thermistor, 103K
SH101
BGTech
8860BEACA1010 Shield CAN, VCO
SH102
BGTech
8860BEAC93010 Shield CAN, PLL
SH103
BGTech
8660BEACA4010 Shield CAN, PA
SH105 MOTOROLA PMDN4149AR Finger Strip TX
Circuit
Ref.
Supplier Supplier Part No. Description
