Motorola GP2000 Service Manual

Circuit Board/Schematic Diagrams and Parts List Section 7 -23
Q702 ÒIC, Audio AmpliÞerÓ Philips TDA8541T/N1 DSIC174004
COIL
:
L102 0 ohm; 0.1W; +-5% Rohm MCR10 EZH J 000 0662057C01
L301 100nH Toko LL1608-FSR10J 2413926N24
L302 100nH Murata C2012C-R10J N/A
L303 1000uH TDK NL453232T-102J
L305 47nH Sagami Elec C2012C-47NG 2413923B12
L306 1uH Sagami Elec C2520C-1R0J 2462587N68
L307 Chip EmiÞl Murata BLM21A121SPT 2480067M02
L312 1uH Toko FSLM2520-1R0J 2485601J13
L313 47nH Sagami Elec C2012C-47NG 2413923B12
L314 56nH Sagami Elec C2012C-56NG 2413923B18
L315 47nH Sagami Elec C2012C-47NG 2413923B12
L317 47nH Sagami Elec C2012C-47NG 2413923B12
L318 1uH Sagami Elec C2520C-1R0J 2462587N68
L401 12nH Sagami Elec. C2012C-12NJ 2462587V23
L402 12nH Sagami Elec. C2012C-12NJ 2462587V23
L403 470nH Toko FSLM2520-R47K 2485602J33
L404 12nH Sagami Elec C2012C-12NJ 2462587V23
L405 12nH Sagami Elec C2012C-12NJ 2462587V23
L406 Airwound Coil Uchida E2-0.30-1.0-4TL N/A
L407 Coil Latest SMD-0314A N/A
L408 Coil Latest SMD-0314A N/A
L409 33nH Toko LL2012-FH33NJ 2413926K17
L410 150nH Sagami Elec C2012C-R15J 2462587V36
L411 470nH Toko FSLM2520-R47K 2485602J33
L413 Airwound Coil Uchida E2-0.40-0.9-3TL N/A
L414 Airwound Coil Uchida E2-0.30-1.7-6TL N/A
L415 Airwound Coil Uchida E2-0.30-1.7-5TL N/A
L416 Airwound Coil Uchida E2-0.30-1.7-5TL N/A
L417 1uH Toko FSLM2520-1R0J 2485601J13
L418 Airwound Coil Uchida E2-0.30-1.0-7TL N/A
L419 Airwound Coil Uchida E2-0.40-0.9-3TL N/A
L420 Airwound Coil Uchida E2-0.40-1.0-5TL N/A
L421 39nH Sagami Elec C2012C-39NJ 2462587V29
L422 Airwound Coil Uchida E2-0.40-0.9-3TL N/A
L423 Airwound Coil Uchida E2-0.30-1.0-6TL N/A
L424 Airwound Coil Uchida E2-0.30-1.0-5TL N/A
L425 68nH Sagami Elec C2012C-68NJ 2462587V32
L426 Airwound Coil Uchida E2-0.30-1.0-4TL N/A
L427 100nH Toko LL1608-FSR10J 2413926N24
L428 100nH Toko LL1608-FSR10J 2413926N24
L429 Chip Beads TDK ZBFS5105-PT N/A
L430 100nH Toko LL1608-FSR10J 2413926N24
L431 2.2uH TDK MLF1608A2R2KT N/A
L501 1uH TDK MLF1608A1R0KT N/A
L702 390nH Sagami Elec C2012C-R39J 2462587V41
JACK
:
CN201 Connector Contact Motorola 09D86237A N/A
CN701 Connector Matsushita
Denko
AXK6S40545J/P DSCN097003
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
J401 Antenna Jack Motorola 02D04852J N/A
J701 Audio Jack Motorola 09R80683Z01 N/A
CERAMIC FILTER
:
F501 455Khz Toko ALFYM455F
F502 455Khz Toko ALFYM455H
CRYSTAL
F401 Not Placed ------------ ------------ ------------
F402 ÒFilter, 45.1 MhzÓ Hertz 45N12A5 (45.1MHz)
UM-5J-SMD
DSXF137006
X301 ÒCrystal, 14.4MHzÓ Nikko Denshi TOP-B 14.4MHz DSXT181001
X501 ÒCrystal, 44.645MHzÓ Nikko Denshi TOP-B 44.645MHz DSXT181002
MISCELLANEOUS
J702 Housing Molex Housing 53047-0210 DSM5075001
SW201 Potentiometer Tocos TP76N17N A10Kohm
10SK
DSVR010008
RV302 ------------ ------------ Not Used ------------
CD501 Discriminator Murata CDBC455CX24-TP DSFL506003
RESISTOR
:
L701 0 ohm; 0.1W; +-5% Rohm MCR10 EZH J 000 0662057C01
R201 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R202 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R203 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R204 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R205 Chip Thermistor Hokuriku NSM3503J400J N/A
R206 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R207 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R208 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R209 10 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 100 0662057A01
R210 22 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 220 0662057A09
R211 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R212 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R301 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R302 220 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 221 0662057A33
R310 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R311 15 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 153 0662057A77
R312 220 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 221 0662057A33
R313 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R314 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R315 2.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 272 0662057A59
R316 1.5 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 152 0662057A53
R317 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R318 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R319 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R320 1.5 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 152 0662057A53
R321 6.8 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 682 0662057A69
R322 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R323 Chip Network Resistor Hokuriku CRA168-472J N/A
R324 Not Placed ------------ ------------ ------------
R325 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R326 Not Placed ------------ ------------ ------------
R327 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number

Motorola GP2000 Specifications

General

Sealing	IP54
Channel Capacity	16 channels
Power Output	5W
Battery Life	8 hours
Weight	350 g
