Motorola GP2000 Service Manual

Section 7 -24 Circuit Board/Schematic Diagrams and Parts List
R328 Not Placed ------------ ------------ ------------
R329 220 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 2203 N/A
R330 Chip Thermistor Murata NTH5G16P39A103K07
TH
N/A
R332 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHF 1003 0662057P95
R333 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R334 3.3 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 332 0662057A61
R335 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R336 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R337 150 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1503 0662057P97
R338 180 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 181 0662057A31
R339 15 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 150 0662057A05
R340 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R341 33 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 333 0662057A85
R342 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R343 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R346 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R347 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R349 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R350 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R355 Not Placed ------------ ------------ ------------
R356 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R357 10 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 100 0662057A01
R358 47 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 470 0662057A17
R359 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R361 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R362 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R363 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 471 0662057A41
R364 2.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 272 0662057A59
R365 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 471 0662057A41
R366 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 471 0662057A41
R401 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R402 5.6 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 562 0662057A67
R403 3.3 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 332 0662057A61
R404 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R405 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 2R2 0662057W09
R406 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R407 10 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 100 0662057A01
R408 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R409 390 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 391 0662057A39
R410 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R411 Not Placed ------------ ------------ ------------
R412 Not Placed ------------ ------------ ------------
R413 56 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 560 0662057A19
R414 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R415 330 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 334 0662057B10
R416 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R418 39 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 390 0662057A15
R419 220 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 221 0662057A33
R420 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R421 120 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 121 0662057A27
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
R422 56 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 560 0662057A19
R423 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R424 12 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 123 0662057A51
R425 Not Placed ------------ ------------ ------------
R426 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R427 12 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 123 0662057A51
R428 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R429 470 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 471 0662057A41
R430 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R431 15 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 153 0662057A77
R432 220 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 221 0662057A33
R433 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R434 10 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 100 0662057A01
R435 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R436 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R437 680 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 681 0662057A45
R438 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 4R7 0662057W17
R439 15 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 153 0662057A77
R440 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R441 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R442 330 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 331 0662057A37
R443 330 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 331 0662057A37
R444 22 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 220 0662057A09
R445 0.1 ohm; 0.5W; +-5% Rohm MCR50 JZH J R10 N/A
R446 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R447 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R448 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R449 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R450 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R451 100 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1003 0662057P95
R452 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R453 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R454 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R455 27 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 273 0662057A83
R456 1 M ohm; 0.1W; +-5% Rohm MCR03 EZHJ 105 0662057B22
R457 15 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 153 0662057A77
R459 560 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 561 0662057A43
R466 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R501 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R502 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R503 2.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 272 0662057A59
R505 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R506 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R507 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R508 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R509 68 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 683 0662057A93
R510 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 474 0662057B14
R511 56 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 563 0662057A91
R512 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R513 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R514 3.3 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 332 0662057A61
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
