Motorola GP2000 Service Manual

Circuit Board/Schematic Diagrams and Parts List Section 7 -25
R515 25.5 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 2552 0662057T92
R516 29.4 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 2942 0662057P29
R517 15.8 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1582 0662057Z03
R518 11.5 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1152 0662057Z35
R519 150 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 1503 0662057P97
R520 4.2 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 4221 N/A
R521 715 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 7153 0662057T99
R522 Not Placed Rohm ------------ ------------
R523 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R524 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R525 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R526 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R527 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R530 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R531 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R532 564 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 564 0662057B16
R534 150 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 154 0662057B02
R535 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R536 1.5 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 152 0662057A53
R537 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 474 0662057B14
R538 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R539 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R540 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R541 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R542 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R543 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R544 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R545 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R546 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R547 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R548 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R549 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R550 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R551 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R560 5.11 K ohm; 0.1W; +-5% Rohm MCR03 EZHF 5111 0662057P06
R561 634 K ohm; 0.1W; +-5% Rohm MCR03 EZHF 6343 N/A
R563 2.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 272 0662057A59
R564 82 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 8202 N/A
R565 15 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 153 0662057A77
R566 18 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 183 0662057A79
R567 10 K ohm; 0.1W; +-10% Rohm NTH5G16P39A103K07
TH
N/A
R568 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R569 1 K ohm; 0.25W; +-5% Hokuriku CR1/4-102J N/A
R601 3.3 M ohm; 0.1W; +-5% Rohm MCR03 EZHJ 335 0662057B34
R602 6.8 K ohm; 0.25W; +-5% Rohm MCR03 EZHJ 682 0662057A69
R604 6.8 K ohm; 0.25W; +-5% Rohm MCR03 EZHJ 682 0662057A69
R605 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R606 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R607 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R608 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number
R609 680 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 684 0662057B18
R610 22 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 223 0662057A81
R611 Chip Thermistor Hokuriku NSM3503J400J N/A
R612 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R615 12 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 123 0662057A75
R616 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R617 220 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 224 0662057B06
R620 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R621 330 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 334 0662057B10
R622 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R625 18 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 183 0662057A79
R626 18 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 183 0662057A79
R627 680 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 684 0662057B18
R628 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R629 Not Placed ------------ ------------ ------------
R631 820 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 824 0662057B20
R632 33 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 333 0662057A85
R633 12 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 123 0662057A75
R634 680 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 684 0662057B18
R635 1.2 M ohm; 0.1W; +-5% Rohm MCR03 EZHJ 125 0662057B24
R636 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R637 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R638 330 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 334 0662057B10
R639 150 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 154 0662057B02
R640 150 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 154 0662057B02
R641 680 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 684 0662057B18
R642 33 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 3302 N/A
R643 22 K ohm; 0.1W; +-1% Rohm MCR03 EZHF 2202 N/A
R645 1 M ohm; 0.1W; +-5% Rohm MCR03 EZHJ 105 0662057B22
R646 1 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 102 0662057A49
R648 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 474 0662057B14
R649 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R650 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R651 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R652 680 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 684 0662057B18
R654 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R655 4.7 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 472 0662057A65
R656 100 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 101 0662057A25
R657 0 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 000 0662057B47
R658 820 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 821 0662057A47
R659 12 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 123 0662057A75
R660 Not Placed ------------ ------------ ------------
R661 10 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 103 0662057A73
R663 100 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 104 0662057A97
R701 2.2 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 222 0662057A57
R702 1.5 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 152 0662057A53
R703 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 474 0662057B14
R704 47 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 473 0662057A89
R705 22 ohm; 0.1W; +-5% Rohm MCR03 EZHJ 220 0662057A09
R706 470 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 471 0662057A41
R707 3.9 K ohm; 0.1W; +-5% Rohm MCR03 EZHJ 392 0662057A63
Circuit Ref Description Vendor
Vendor Part
Number
Motorola Equivalent
Part Number

Motorola GP2000 Specifications

General

Sealing	IP54
Channel Capacity	16 channels
Power Output	5W
Battery Life	8 hours
Weight	350 g
