xii 68P02948C90-O February 1997
Foreword GTX/GTX LTR/LTS 2000 Portable Radios Service Manual
Service Tools
Service Tools
The following table lists the tools recommended for working on this family of radios; these tools are also available
from Motorola. Note that the R-1319A workstation requires the use of a specific “heat focus head” for each of the
components on which this item is used. Each of these heat focus heads must be ordered separately. The individual
heat focus heads (and the components on which they are used) are listed at the top of the next page.
MOTOROLA NO. DESCRIPTION APPLICATION
6680387A59 Extractor, 2-contact Removal of discrete surface-mounted devices.
6680387A64 Heat controller with safety stand, or
6680387A65 Safety stand only
0180381B45 110 Vac or
0180300E06 220 Vac
MBT250 Surface-mount/ thru-hole repair
station
Temperature-controlled, self-contained solder-
ing/desoldering repair station for installation
and removal of surface-mounted devices.
8180369E97 Flux holder/applicator arrays for repair.
Allows for the proper amount of flux to be
applied to pad grid.
1105139W02 30cc plastic syringe and flux paste For use with flux holder/applicator
8180369E97.
0180386A81 Miniature digital readout soldering station
(incl. 1/64” micropoint tip)
0180386A78 Illuminated magnifying glass with lens at-
tachment
0180386A82 Anti-static grounding kit Used during all radio assembly and disassem-
bly procedures.
6684253C72 Straight prober
6680384A98 Brush
1010041A86 Solder (RMA type), 63/37, 0.020" diameter
1 lb. spool
1080370B43 RMA liquid flux
R-1319A Shields and surface-mounted component -
IC removal/rework station (order all heat
focus heads separately)
Removal of surface-mounted integrated cir-
cuits.
To Next Page
