Motorola GTX Service Manual

February 1997 68P02948C90-O v
GTX/GTX LTR/LTS 2000 Portable Radios Service Manual Foreword
GTX and GTX LTR Portable Radios Model Chart
GTX and GTX LTR Portable Radios Model Chart
GTX Portable Radio, H11WCD4CB1AN: GTX LTR Portable Radio, H11WCD4CU1AN
FUF1194 900 MHz 1.5 ppm GTX Portable Radio
FUF1199 900 MHz 1.5 ppm GTX LTR Portable Radio
HNN9628 Battery (7.5 V rechargeable)
NAF5038 1/2 Wavelength Whip 900 MHz
KIT BREAKDOWN
FUF1194 900 MHz 1.5 ppm Portable Radio: FUF1199 900 MHz 1.5 ppm GTX LTR Portable Radio:
FLN2436 Front Unit
FUF1196 1.5 ppm RF Unit
FLN8577 Miscellaneous Parts
FLN2436 Front Housing
FHN5873 Housing
FEN1650 Logic Board & I/O Unit
FSN5509 Speaker & Microphone Assembly
FLN8574 Miscellaneous Parts
FEN1650 Logic Board & I/O Unit
FLN8836 Logic Board
FLN8515 I/O Hardware
FUF1196 1.5 ppm RF Unit
FUF5690 1.5 ppm RF Board
FLN2394 Chassis Assembly
FLN8575 Shield & Parts
FLN2394 Chassis Assembly
FLN8517 Battery Filter Board
FLN8518 Chassis Hardware
Not all kits on this page will be available from the Americas Parts Division
