Motorola HT1250 User Manual

19
English
GETTING STARTED
Attaching the Battery Removing the Battery
1 Fit the extensions at the bottom of the battery
into the bottom slots on the radio.
2 Press the top part of the battery toward the
radio until you hear a click.
②
1
2
1 Turn off the radio (see page 22).
2 Slide both battery latches downward.
3 Pull the top part of the battery away from the
radio.
3
2
Battery
Latches
GettingStarted.fm Page 19 Monday, September 30, 2002 2:08 PM

Motorola HT1250 Specifications

General

Power Output	1-5W (VHF), 1-4W (UHF)
Emergency Button	Yes
IP Rating	IP54
Frequency Range	136-174 MHz (VHF), 403-470 MHz (UHF)
Keypad	Limited Keypad
Signaling	MDC1200, DTMF, Quick Call II
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Channel Capacity	128 channels
Dimensions	137 mm x 57.5 mm x 37.5 mm
Display	Yes, alphanumeric
