22
English
GETTING STARTED
Attaching the Side Connector Cover
TURNING THE RADIO ON OR OFF
1 Place the loop (attached to the side connector
cover) over the antenna; then slide it
downward until it touches the top of the radio.
2 Insert the tab on the top of the cover into the
slot above the connector.
3 Position the cover over the connector and
align the thumbscrew with the threaded hole
in the radio.
4 Tighten the thumbscrew to hold the cover in
place. Do not overtighten the thumbscrew.
Loop
Slot
Thumbscrew
Antenna
ON OFF
Turn the On/Off/
Volume Control knob
clockwise.
If power-up is suc-
cessful, you will hear
the Self-Test Pass
Tone
and see the LED turn
green.
If the radio fails to
power up, you will
hear the Self-Test Fail
Tone .
Turn the On/Off/
Volume Control knob
counterclockwise until
you hear a click.
GettingStarted.fm Page 22 Monday, September 30, 2002 2:08 PM
