1 - 4 MC3000 User Guide
Figure 1-2 MC3000 Imager and MC3000 Laser Mobile Computers (Back View)
Rotating Scan Turret
The MC3000R mobile computer features a Rotating Scan Turret with three position stops. This feature offers
greater scanning flexibility.
Figure 1-3 Rotating Scan Turret
Strap/Door
Assembly
Scan Window
Stylus
MC3000S
MC3000R
Latches
Strap/Door
Assembly
Screws
Stylus
Holder
Headset Jack
(optional)
Headset Jack
(optional)
Scan Window
Position Stop
Position Stop
Position Stop
