4 - 4 MTM700 Mobile Terminal / Basic Service Manual PROGRAMMING THE RADIO
After a successful writing, the message “The operation was successful” appears
on the computer screen.
5. Press the OK button.
Frequency Programming
Carry out the following steps if you need to add or change the radio frequencies.
Note: Save your radio factory frequencies before you start programming by using (Menu
Bar located on the CPS Application Window Screen) “File- Save as” (Your selected
File name).
1. In the “Codeplug Tree” select “System Parameters”.
• Click on “Frequency List”.
• Click on “List No. 2”.
• At the top of list 2, write the three frequencies which you have selected (the
following frequencies are for example only):
For 380-430 MHz Radios
Rx 420.0125MHz (IFR 800)
Rx 425.0125MHz (IFR 1000)
Rx 429.9875MHz (IFR 1199)
For 806-870 MHz Radios
Rx 851.0125MHz (IFR 2040)
Rx 860.0125MHz (IFR 2400)
Rx 869.9875MHz (IFR 2799)
2. Press the write phone icon.
3. Disconnect the radio from the programming kit.
Note: The new programmed frequencies of the radio are now available to be tested with
the IFR or for any other use.
List1 and 2 frequencies are saved in the CodePlug and may only be accessed by
performing the following steps. When performing steps 4 thru 10, make sure that
you press the radio keys sequentially (less then a second between every consecu-
tive press):
4. Press the “Right” navigation key.
5. Press the “1” key, and “Menu” key.
6. Press the “2” key, and “Menu” key.
7. Press the “3” key.
