Motorola MTP3100 User Manual

Chapter 2
Getting Started
Familiarize yourself with basic information on how to use the radio.
2.1
Product Technical Information
Table 2: Product Technical Information
Description Value
Maximum Voltage 4.2 V
Maximum Current 4.7 A
Maximum RF Power 1 or 1.8 W (switchable)
Maximum Speaker
Load
2 W at 16 Ω
Antenna Impedance 50 Ω
Operating Tempera-
ture Range
-30 °C to +60 °C
Storage Temperature
Range
-40 °C to +85 °C
Ingress Protection
Rating
IP65, IP66, and IP67
Audio Power Through
the Radio and Acces-
sories
RMS: 2 W
Peak Power: 4 W
Operating Time Duty Cycle Class 4 (1 W) Class 3L (1.8 W)
Standard 1650 mAh
Battery
05/05/90
05/35/60
> 16 h
> 12 h
> 15 h
> 11 h
1950 mAh Battery 05/05/90
05/35/60
> 18 h
> 13 h
> 17 h
> 12 h
2200 mAh Battery 05/05/90
05/35/60
> 21 h
> 16 h
> 20 h
> 15 h
3400 mAh Battery 05/05/90 > 30 h > 28 h
68015000899-FH
Chapter 2: Getting Started
18
