LED Codes
4
3 LED Codes
The RFS6010 RF Switch has four vertically-stacked LEDs on its front panel. Each of the switch’s
Gigabit Ethernet ports have two status LEDs. These LEDs display two colors (green & amber), and
three lit states (solid, blinking, and off). The following tables decode the combinations of LED colors
and states for the System Status LEDs and the Gigabit Ethernet LEDs.
3.1 System Status LEDs
System Status 1
Fan status
Temperature status
System Status 2
