Motorola RFS6000 Series User Manual

Hardware Setup
12
expansion. For software configuration, please see the Motorola RF Switch System Reference
available from the Motorola website.
4.2 Gigabit Ethernet on the RFS6010 RF Switch
The RFS6010 RF Switch has nine RJ-45 Gigabit Ethernet ports and one Gigabit SFP (fiber optic) port.
Using the RJ-45 ports requires connecting a Category-6 Ethernet cable to the port. Each of the eight
ports support Power-over-Ethernet. To use the Gigabit SFP port, first install the SFP Module (Motorola
Part Number: Fiber-3000-1S-WWR).
System LEDs:
System Status 1
System Status 2
Fan Status
Temperature Status
Gigabit Ethernet
RJ-45 connectors
with per-port LEDs
USB
port
Console
connector
Out-of-band
management
port
ExpressCard
UPLINK
