About Wi-Fi Protected Security Feature (WPS)
The WPS Pairing button activates any Wi-Fi Protected Security (WPS) enabled device and
automatically connects it to the SBG6580 Wi-Fi network.
To increase the bandwidth available for receiving and transmitting data, your service
provider may implement bonded channels for the RECEIVE and SEND features.
Rear Panel
Note: The USB port is not included on all SBG6580 models. This guide provides
instructions for Ethernet connectivity unless specified.
PORT DESCRIPTION
1
Connected LED
• Green LED is ON — Indicates a data connection is made
2 USB*
For Windows computers only — DO NOT use the USB port to connect a
Mac, UNIX, or Linux computer
3 RESET
Returns modem to default settings (custom configurations are removed)
and restarts the cable modem
4 CABLE
Coaxial cable connector
5
+12VDC Power connector
Product Overview •
Motorola SURFboard • User Guide 4
