Installation and Overview
VAP2400 Wireless Video Bridge • Installation Manual 8
Rear Panels
Four Port
1
2
3
4
Single Port
2
3
4
1
1 Reset Button Resets the VAP to its default settings
2 WPS Button Establishes wireless connection to your home network
3 Ethernet Port Connects to an Ethernet-equipped computer, hub, or switch using an
RJ-45 cable connection.
4 Power Jack Provides power to the VAP2400
