motortronics MVC Plus - Page 51

- 47 -
SP.4 设置页面 4 继电器分配（Relay Assignment）
Page 4
Relay Assignment
MENU
I/B TRIP
1ST: TRIP
S/C TRIP
1ST: TRIP ONLY
OVERCURRENT TRIP
1ST: TRIP
STATOR RTD TRIP
1ST: NONE
NON-STATOR RTD TRIP
1ST: NONE
G/F HI SET TRIP
1ST: TRIP
G/F LO SET TRIP
1ST: TRIP
PHASE LOSS TRIP
1ST: TRIP
ACCEL. TIME TRIP
1ST: TRIP ONLY
START CURVE TRIP
1ST: TRIP ONLY
OVER FREQUENCY TRIP
1ST: TRIP
UNDER FREQUENCY TRIP
1ST: TRIP
I*I*T START CURVE
1ST: TRIP
O/L TRIP
1ST: TRIP ONLY
PHASE REVERSAL
1ST: TRIP
OVERVOLTAGE TRIP
1ST: TRIP
UNDERVOLTAGE TRIP
1ST: TRIP
POWER FACTOR TRIP
1ST: NONE
TACH ACCEL TRIP
1ST: NONE
INHIBITS TRIP
1ST: ALARM
SHUNT TRIP
1ST: NONE
BYPASS DISCREPANCY
1ST: NONE
TCB FAULT
1ST: TRIP
EXTERNAL INPUT #2
1ST: NONE
DUAL RAMP
1ST: NONE
THERMOSTAT
1ST: TRIP
O/L WARNING
1ST: ALARM
OVERCURRENT ALARM
1ST: ALARM
SCR FAIL SHUNT ALARM
1ST: NONE
MOTOR RUNNING
1ST: AUX3
I/B ALARM
1ST: ALARM
STATOR RTD ALARM
1ST: NONE
NON-STATOR RTD ALARM
1ST: NONE
RTD FAILURE ALARM
1ST: NONE
SELF-TEST FAIL
1ST: TRIP
THERMAL REGISTER
1ST: ALARM
U/V ALARM
1ST: ALARM
O/V ALARM
1ST: ALARM
POWER FACTOR ALARM
1ST: NONE
KW DEMAND ALARM
1ST: NONE
KVA DEMAND ALARM
1ST: NONE
KVAR DEMAND ALARM
1ST: NONE
AMPS DEMAND ALARM
1ST: NONE
LEARNED START CURVE
1ST: TRIP
GROUND FAULT ALARM
1ST: ALARM
UNDERCURRENT ALARM
1ST: NONE
TIMED OUTPUT
1ST: NONE
RUN DELAY TIME
1ST: NONE
AT SPEED
1ST: AUX4
继电器分配
LOW CONTROL VOLTAGE
1ST: TRIP ONLY
过载跳闸
电流不平衡跳闸
短路跳闸
过流跳闸
定子RTD超温跳闸
非定子RTD超温跳闸
接地故障高限位跳闸
接地故障低限位跳闸
缺相跳闸
加速时间跳闸
起动曲线跳闸
超频跳闸
低频跳闸
I*I*T起动过载曲线
继电器分配
反相
过电压跳闸
低电压跳闸
功率因数跳闸
测速器加速跳闸
有关时间锁定跳闸
分流跳闸
旁路不同步
控制电压低
TCB板故障
外部输入#2
双斜坡
热开关
过载报警
过流报警
可控硅短路报警
接地故障报警
说明：本页面选项均为TRIP (跳闸 AUX1)、
ALARM (报警AUX2)、AUX3、AUX4、无 (NONE)
低电流报警
电动机运行
电流不平衡报警
定子RTD超温报警
非定子RTD超温报警
RTD故障报警
自检故障
热寄存器
低电压报警
过电压报警
功率因数报警
有功功率报警
总功率报警
无功功率报警
电流有效值报警
计时器输出
运行延时
全速
