Supplied Par ts List
2
CAUTION!
WARNING
!
The monitor desktop mount must be evenly positioned on a
stable horizontal surface. If the mount is not positioned in a
balanced manner, it may fall, resulting in possible injury
and/or damage. The optional desktop bolt may be used to
provide additional stability.
(1)Support Plate-j(1)M10 Bolt-i (1)M10 Washer-k (1)Spring Washer-l
(8)M4 Spacer-s(8)M4x12 Bolt-q (8)M4x30 Bolt-r
(1) Grommet Base
Plate-m
(1)Wire Clip-n1 (1)Allen Key-o
(1)Wrench-p
Tools Required
Phillips Screwdriver
(4)Wire Clip-n2
(1) Pole-a (1) Swivel Arm-c(1) Weighted Base-b
(2) VESA Plate-d (2) Nut-h
(3) M5x14 Bolt-e
To Next Page
