Mount-It! 2781 - Attach the VESA Plate to the Monitor; VESA Plate for Flat Back Monitors; VESA Plate for Curved or Recessed Back Monitors

5
Step 3
Attach the VESA Plate to the Monitor
For Monitor with Curved or
Recessed Back
s
r
Step 4
Slide the Monitor onto the Head of Swivel Arm
Install the security Nut(h). Make
sure the security nut is installed
before you rotate the monitor.
Slide the monitor onto the head of
Swivel Arm(c) as shown in the
above diagram.
h
For Monitor with Flat Back
q
