EN - 175
KD 986 – OPERATING INSTRUCTIONS FOR USE OF THE
CONTROL UNIT
Specifications
• Rated voltage: 24 V / 36 V / 48 V DC
• Operating current: 50 mA
• Maximum operating current: 200 mA
• of leakage current in off state: <1 μA
• Operating temperature: -20 ~ 45 °C
• Storage temperature: - 20 ~ 60 °C
• Degree of protection: IPX6
• Humidity: 30% - 70%
Appearance and Size
Display appearance and dimension figure (unit: mm)
