Mowox DYM1678D-3 User Manual

11
Fig. 6A Fig. 6B (only for DYM1560EDQ)
5.6 STARTER BATTERY (nur DYM1560EDQ)
5.6.1 DEPLOY
1. Insert the battery into the guide rail on the side of the motor. (Fig. 7A/7B)
2. Push the battery in the middle until you feel it click into place.
Fig. 7A Fig. 7B
5.6.2 REMOVE
1. Press both buttons on the side of the battery together. (Fig.7C)
2. Hold down the buttons and pull out the battery. (Fig. 7D)
Fig.7C Fig. 7D
Warning: Check for damage and recharge after each use.

Mowox DYM1678D-3 Specifications

General

Brand	Mowox
Model	DYM1678D-3
Category	Lawn Mower
Language	English
