Moxa Technologies NPort 5000AI-M12 Series Quick Installation Guide

- 8 -
Female DB9 to Male DB9
Specifications
Physical Characteristics
Housing
Metal, IP40 protection
Dimensions
80 x 216.6 x 52.9 mm (3.14 x 8.53 x 2.08 in)
Environmental Limits
Operating Temperature
• Standard Models:
-25 to 55°C (32 to 140°F)
• Wide Temperature Models:
-40 to 75°C (-40 to 167°F)
Operating Humidity
5 to 95% RH
Storage Temperature
-40 to 85°C (-40 to 185°F)
Conformal coating
Available on –CT models
Power Input (Need to modularize)
Input Voltage
12/24/36/48 VDC (8.4 to 60 VDC)
Power Consumption
NPort 5150AI-M12: 310 mA @12V
NPort 5150AI-M12-CT: 310 mA @12V
NPort 5150AI-M12-T: 310 mA @12V
NPort 5250AI-M12: 360 mA @12V
NPort 5250AI-M12-CT: 360 mA @12V
NPort 5250AI-M12-T: 360 mA @12V
NPort 5450AI-M12: 440 mA @12V
NPort 5450AI-M12-CT: 440 mA @12V
NPort 5450AI-M12-T: 440 mA @12V
Connector
M12 5-pin male connector
Power Line Protection
Meets EN 50155 certification
Regulatory Approvals
EMC
CE (EN 55032 Class A, EN 55024) (EMI),
FCC Part 15 Subpart B Class A (EMS)
Safety
UL (UL60950-1)
Rail Traffic
EN 50155*, EN 50121-4
*Complies with a portion of EN 50155 specifications. Please contact
Moxa or a Moxa distributor for details.
Shock
IEC 61373
Vibration
IEC 61373
Freefall
IEC 60068-2-32
Reliability
Alert Tools
Built-in buzzer and RTC
