NPort 5600 Series (Rackmount)
LED Name
LED Color
LED Function
Ready
Red
Steady on:
Power is on and the NPort is booting up.
Blinking:
Indicates an IP conflict, or the DHCP or BOOTP server did not
respond properly.
Green
Steady on:
Power is on, and the NPort is functioning normally
Blinking:
The device server has been located by NPort Administrator’s
Location function.
Off
Power is off, or a power error condition exists.
Tx/Rx,
P1 to P16
Orange
The serial port is receiving data.
Green
The serial port is transmitting data.
Off
Data is NOT being transmitted or received through the serial port.
LAN
Green
The Ethernet port is connected, but data is NOT being transmitted.
Blinking
The Ethernet port is connected, and data is being transmitted.
Off
The Ethernet port is disconnected.
PWR
Green
Power cable is connected and provides electricity properly.
Off
Power cable is disconnected.
NPort 5600-8-DT/DTL Series
LED Name
LED Color
LED Function
PWR
Red
Power is on.
Off
Power is off.
Ready
Green
Steady on:
The NPort is operational.
Blinking:
The NPort is responding to NPort Administrator’s Location
function, or the NPort is being reset to factory defaults.
Off
Power is off, or power error condition exists.
Fault
Red
Indicates an IP conflict, or the DHCP or BOOTP server did not respond
properly.
Off
No fault condition detected.
Off
Blinking:
Network is connected, data is being transmitted.
ETH 1, ETH2
Green
Steady on
Network is connected, no data is being transmitted.
Off
Blinking
Network is connected, data is being transmitted.
In Use
(P1 to P8)
Green
Serial port has been opened by server side software.
Off
Serial port is not currently opened by host side software.
Tx/Rx
(P1 to P8)
Green (Tx)
Serial device is transmitting data.
Orange(Rx)
Serial device is receiving data.
Off
No data is flowing to or from the serial port.
NPort 5000AI-M12 Series
LED Name
LED Color
LED Function
PWR
Green
Power is being supplied to the power input.
Ready
Red
Steady on:
Power is on, and the NPort is booting up.
Blinking:
Indicates an IP conflict, or the DHCP or BOOTP server did not
respond properly.
Green
Steady on:
Power is on, and the NPort is functioning normally
Blinking:
The device server has been located by NPort Administrator’s
Location function.
Off
Power is off, or a power error condition exists.
10M, 100M
Orange
The device is connected to a 10 Mbps Ethernet connection.
Green
The device is connected to a 100 Mbps Ethernet connection.
Off
The Ethernet cable is disconnected, or has a short.
P1, P2, P3, P4
Orange
The serial port is receiving data.
Green
The serial port is transmitting data.
Off
Data is NOT being transmitted or received through the serial port.
