NPort 5200 Series Introduction
1-3
Product Specifications
Ethernet Interface
Number of Ports:
1
Speed:
10/100 Mbps, auto MDI/MDIX
Connector:
8-pin RJ45
Magnetic Isolation Protection:
1.5 KV built-in
Serial Interface
Number
of Ports: 2
Serial Standards:
NPort 5210: RS
-232
NPort 5230: 1 RS
-232 port, 1 RS-422/485 port
NPort 5232/5232I: RS
-422/485
Connector:
NPort 5210: RJ45 (8 pins)
NPort 5230/5232/5232I: Terminal Block (5 contacts per port)
Serial Line Protection:
15 KV ES
D protection for all signals
2 KV isolation protection (NPort 5232I/5232I
-T)
RS
-485 Data Direction Control: ADDC® (automatic data direction control)
Serial Communication Parameters
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 1.5, 2
Parity:
None, Even, Odd, Space, Mark
Flow Control:
RTS/CTS (RS-232 only), DTR/DSR (NPort 5210 only), XON/XOFF
Baudrate:
110 bps to 230.4 Kbps
Serial Signals
RS
-232:
NPort 5210: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
NPort 5230: TxD, RxD, RTS, CTS, GND
RS
-422: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-2w: Data+, Data-, GND
Software
Network Protocols:
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP
Configuration Options:
Web Console, Serial Console (NPort 5210/5230 only), Telnet Console, Windows
Utility
Windows Real COM Drivers:
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64,
Windows 2012 x64, Embedded CE 5.0/6.0, XP Embedded
Fixed TTY Drivers:
SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6,
Solaris 10, FreeBSD, AIX 5.x, HP
-UX 11i
Linux Real TTY Drivers:
Linux kernel 2.4.x, 2.6.x, 3.x
Physical Characteristics
Housing:
Metal
Weight:
NPort 5210: 340 g
NPort 5230/5232: 360 g
NPort 5232I: 380 g
