NPort 5200 Series Introduction
1-4
Dimensions:
NPort 5210/5230/
5232:
Without ears: 67 x 100.4 x 22 mm (2.64 x 3.95 x 0.87 in)
With ears: 90 x 100.4 x 22 mm (3.54 x 3.95 x 0.87 in)
NPort 5232I:
Without ears: 67 x 100.4 x 35 mm (2.64 x 3.95 x 1.37 in)
With ears: 90 x 100.4 x 35 mm (3.54 x 3.95 x 1.37 in)
Environmenta
l Limits
Operating Temperature:
Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5 to 95% (non-condensing)
Power Requirements
Input Vol
tage: 12 to 48 VDC
Power Consumption:
NPort 5210: 325 mA @ 12 V, 190 mA @ 24 V
NPort 5230: 325 mA @ 12 V, 190 mA @ 24 V
NPort 5232: 280 mA @ 12 V, 150 mA @ 24 V
NPort 5232I: 365 mA @ 12 V, 200 mA @ 24 V
Standards and Certifications
Safety:
UL 60950-1, EN 60950-1
EMC:
CE, FCC
EMI:
EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS:
EN 55024
Marine:
DNV
Medical:
(NPort 5210 only)
EN 60601
-1-2 Class B, EN 55011
Reliability
Alert Tools:
Built-in buzzer and RTC (real-time clock)
Automatic Reboo
t Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures):
NPort 5210: 134,850 hrs
NPort 5230: 106,955 hrs
NPort 5232: 102,344 hrs
NPort 5232I: 87,083 hrs
Warranty
Warranty Period:
5 years
Details:
See www.moxa.com/warranty
