Moxa Technologies NPort 5210A Quick Installation Guide

- 6 -
Specifications
Power Requirements
Power Input
12 to 48 VDC
Power Consumption
119 mA @ 12V, 65 mA @ 24V
Environmental Limits
Operating Temperature
Standard Models:
0 to 60°C (32 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Ambient Humidity
5 to 95% RH
Dimensions
With ears
100 x 111 x 26 mm (3.94 x 4.37 x 1.02 in)
Without ears
77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in)
Protection
Serial Line Protection
Level 1 Surge, EN61000-4-5
Magnetic Isolation
1.5 KV for Ethernet
Power Line Protection
Level 2 Burst (EFT), EN61000-4-4
Level 3 Surge, EN61000-4-5
Regulatory Approvals
FCC Class A, CE Class A, UL, LVD

Moxa Technologies NPort 5210A Specifications

General

Baud rate	230.4 Kbit/s
Data bits	5, 6, 7, 8
Stop bits	1, 1.5, 2
Certification	CE, FCC
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
Flow control support	Yes
Serial interface type	RS-232
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Mean time between failures (MTBF)	134850 h
Product color	Black, Blue
Housing material	Metal
Input voltage	12 - 48 V
Power consumption	325 mA
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	90 x 100.4 x 22 mm
