Moxa Technologies NPort 5450AI-M12 User Manual

NPort 5000 Series User Manual
6
1. About This Manual
Read this user’s manual to learn how to configure and use your Moxa NPort device server. The following
products are covered by this manual:
NPort Family
Model Series
Introduction
NPort 5000
NPort 5110/5130/5150 Series
NPort 5210/5230/5232 Series
NPort 5410/5430/5450 Series
NPort 5610/5630/5650 Series
NPort 5610-8-DT/5650-8-DT Series
NPort 5610-8-DTL/5650-8-DTL Series
NPort 5000 series device servers are
designed to make serial devices network-
ready in an instant. The different form
factors of the servers provide flexible
options for users to connect legacy
devices to an IP-based Ethernet LAN.
NPort 5000A
NPort 5110A/5130A/5150A Series
NPort 5210A/ 5230A/5250A Series
NPort 5150AI-M12/5250AI-M12/5450AI-M12
Series
NPort P5150A Series
The NPort 5000A device servers are
designed to make serial devices network-
ready in an instant and give your PC
software direct access to serial devices
from anywhere on the network. The
NPort 5000A device servers are ultra-
lean, rugged, and user-friendly, making
simple and reliable serial-to-Ethernet
solutions possible.
NPort
IA5000/IA5000A
NPort IA5150/IA5250 Series
NPort IA5150A/IA5250A/IA5450A Series
NPort IA device servers are an ideal
choice for establishing network access to
RS-232/422/485 serial devices, including
PLCs, sensors, meters, motors, drives,
barcode readers, and operator displays.
All models are housed in a compact,
rugged, DIN-rail mountable housing, and
come with redundant power inputs,
cascading Ethernet ports, and industrial-
grade certifications.

Moxa Technologies NPort 5450AI-M12 Specifications

General

Certification	CE, FCC, EN 55022 Class A, FCC Part 15 Subpart B Class A, EN 55024, EN 50155, EN 50121-4, IEC 60068-2-6
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow control support	Yes
Serial interface type	RS-232/422/485
Serial ports quantity	4
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2, LLDP
Input voltage	12 - 48 V
Operating temperature (T-T)	-25 - 55 °C
Safety	UL 60950-1, EN 60950-1
Compatible operating systems	Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64, 2012 x64\\r SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac 10.3\\r Linux kernel 2.4.x, 2.6.x, 3.x

Weight and Dimensions

Weight	686 g
Dimensions (WxDxH)	80 x 216.6 x 52.9 mm
