FM8 AL CC
(2) .438
HOLES
1.50 2.68 5.24
4.17
3.48
6.11
10.30
.45
1/4" NPT
PIPE PLUG
2" NPT
SUCTION
.8765
.8755
(4) .344
THRU HOLES
4.50
45°
(4)
.438 THRU HOLES
EQ. SPACED AS SHOWN
ON A
5.875 B.C.
4.505
4.502
2" NPT
DISCHARGE
1/2" NPT
PIPE PLUG
12.79
3.00 3.25
8.50
1/2" NPT
PIPE PLUG
Figure 21
FM8 AL PED
12.79
9.31
3.00 3.25
6.25
(2)
.44
HOLES
.38
8.50
1/2"
PIPE PLUG
6.11
14.66
1.56
4.17
1.79
.750
.749
3.48
5.56 5.24
2" NPT
DISCHARGE
2" NPT
SUCTION
1/4" NPT
PIPE PLUG
(4)
.41
HOLES
5.00
6.00
2.44
Figure 22
FM8 AL PEM
6.05
4.17
5.18
10.36
3.66
1/4" NPT
PIPE PLUG
2" NPT
SUCTION
2" NPT
DISCHARGE
12.79
2.50
5.25
2.75
.38
(2)
.44
HOLES
8.50
1/2" NPT
PIPE PLUG
(4)
.375 DRILL
EQ. SPACED AS SHOWN
ON A
3.625 B.C.
1.623
1.621
.7515
.7505
45° TYP.
